1.2738 P20+Ni 3Cr2NiMnMo Plastic mold tool steel
Main Products: 1.2738, P20+Ni, 3Cr2NiMnMo
| 1.2738 P20+Ni 3Cr2NiMnMo Supply Situation | ||
| Flat Bar | Round bar | |
| Thickness/ Dia | 20 – 1200mm | 13 – 300mm |
| Surface | Black Surface | Black Surface / Turned surface |
| Delivery Condition | Hot Rolled / Hot Forged ; Pre – hardened 33 – 37HRC / Pre – hardened 38 – 42HRC | Hot Rolled / Hot Forged ; Pre – hardened 33 – 37HRC / Pre – hardened 38 – 42HRC |
Products
Related Products
1.2083 420 4Cr13
1.2085 420FM X33CrS16
1.2311 P20 3Cr2Mo
1.2316 AISI 422 X38CrMo16
1.2738 P20+Ni 3Cr2NiMnMo Plastic mold tool steel
1.2738 die steel is one kind of plastic mold steel, we have the 1.2738 tool steel plate, flat bar and round bar. as usual, the hardness of 1.2738 alloy tool steel is 33 – 37HRC. we have the higher hardness with 38-42HRC 1.2738 steel flats1.2738 tool steel is specially designed for plastic mold industry, especially for big steel mold parts.
1.2738 mold steel materials are good used for plastic mold industry, especially for big steel mold parts. such as die casting dies and injection moulds, synthetic plastic moulds dies.
1.2738 Tool Steel International Standard
| DIN | GB | CHINA |
| 1.2738 | P20 + NI | 3Cr2NiMnMo |
1.2738 Tool Steel Chemical Composition
| C | Si | Mn | P | S | Cr | Mo | Ni |
| 0.35-0.46 | 0.20-0.40 | 1.2-1.6 | ≤0.035 | ≤0.035 | 1.80-2.20 | 0.15-0.25 | 0.8-1.2 |
1.2738 Tool Steel Available Size
| Flat Bar Size(mm) | Round Bar Size(mm) | |||
| Thickness | Width | Length | Diameter | Length |
| 20-1200 | 155-2300 | 1500-5800 | 13-300 | 2000-6000 |
1.2738 Tool Steel Delivery Condition
Black Surface / Milling Surface / Turning Surface
Hot Rolled / Forged；Pre – hardened 33 – 37HRC or 38 – 42HRC
1.2738 Tool Steel Delivery time
The stock 1.2738 plates will be delivered within 7-15 days
The customized, will be about 25 – 35 days
