DC53 Cold Work Die Steel And Tool Steel
Main Product: DC53 Flat Bar, DC53 Round Bar
| DC53 Supply Situation | ||
| Flat Bar | Round bar | |
| Thickness/ Dia | 10 – 200mm | 10 – 300mm |
| Surface | Black Surface / Milling or machined surface | Black Surface / Turned surface |
| Delivery Condition | Hot Rolled / Hot Forged ;EAF/ ESR ; Annealed | Hot Rolled / Hot Forged ; EAF/ ESR ; Annealed |
Products
Related Products
Cr12MoV
D2 1.2379 SKD11 Cr12Mo1V1
D3 Cr12 SKD1
O1 1.2510 SKS3 9CrW
DC53 Cold work mould steel for metal steel alloy die
DC53 Cold work mould steel is an improvement over alloy tool steel D-2 specified in
Standard (JIS) G4404. It eliminates the disadvantages of insufficient hardness and toughness, resulting from high-temperature tempering found with D-2, and is intended to replace D-2 in use for general purpose and precision dies.
DC53 Cold work mould steel Tool Steel International Standard
| DIN | JIS | SWEDEN | AISI |
| – | DC53 | ASSAB88 | – |
DC53 Cold work mould steel Tool Alloy Steel Chermical Compisition(Wt%)
| C | Si | Mn | Cr | Mo | V | P | S |
| 0.8-1.2 | 0.80-1.20 | ≤0.50 | 7.5-8.5 | 1.6-2.4 | 0.2-0.6 | ≤0.03 | ≤0.03 |
DC53 Cold work mould steel Flat Bar Available Size(mm)
| Flat Bar Size | Round Bar Size(mm) | |||
| Thickness | Width | Length | Diameter | Length |
| 10-200 | 155-810 | 2000-6000 | 10-300 | 3000-6000 |
DC53 Flat Bar Round Bar Delivery Condition
Black Surface / Milling Surface / Turning Surface
Hot Rolled / Forged; EFA / ESR; Annealed
DC53 Tool Steel Delivery Time
Stock: within 10-15 days.
Future goods: 30-35 days.
