Location: Home > Products > Alloy Mechanical Steel > SAE4340 1.6511 SNCM439 40CrNiMo
SAE4340 1.6511 SNCM439 40CrNiMo Mechanical Alloy Steel
Main Products: SAE4340, 1.6511, SNCM439, 40CrNiMo.
| SAE4340 1.6511 SNCM439 40CrNiMo Supply Situation | ||
| Flat Bar / Plates | Round bar | |
| Thickness/ Dia | 10-300mm | 16 -450mm |
| Surface | Black Surface | Black Surface/ Turned Surface |
| Delivery Condition | Hot Rolled / Hot Forged ; Annealed / Q+T ; Two cutting side / Four Cutting Side | Hot Rolled / Hot Forged ; Annealed / Q+T ; |
Products
Related Products
SAE4140 1.7225 SCM440 42CrMo
SAE5140 1.7035 SCr440 40Cr
SAE52100 EN31 GCr15
SAE4340 1.6511 SNCM439 40CrNiMo Mechanical Alloy Steel
SAE4340 1.6511 SNCM439 40CrNiMo alloy steel is mainly used to make high-strength parts, such as aircraft engine shafts, shafts, gears, fasteners, etc.
SAE4340 1.6511 SNCM439 40CrNiMo alloy steel has high hardenability and is suitable for various high-strength and high-wear-resistant applications.
SAE4340 International Standard:
| GB | JIS | AISI | DIN | BS |
| 40CrNiMo | SNCM439 | SAE4340 | 1.6511 | EN24 |
SAE4340 Chemical composition(%)
| C | Si | Mn | Cr | Mo | P | S | Cu | Ni |
| 0.37-0.45 | 0.17-0.37 | 0.50-0.80 | 0.60-0.90 | 0.15-0.25 | ≤0.035 | ≤0.035 | ≤0.30 | 1.25-1.65 |
SAE4340Available Size(mm) :
| Plate Size(mm) | Flat Bar Size(mm) | Round Bar Size(mm) | |||||
| Thickness | Width | Length | Thickness | Width | Length | Diameter | Length |
| 10-300 | 2000-2300 | 5800-6000 | 10-300 | 210-1300 | 2000-2300 | 16-450 | 3000-6000 |
SAE4340 Delivery Condition:
Black Surface
Hot Rolled / Forged ; Q+T ; Two cutting side / Four Cutting Side
SAE4340 Delivery Time:
The stock SAE4340 sizes will be delivered within 10-15 days.
The customized, will be about 30-35 days.
